Hexagon Elbow Bracket

Hexagon Elbow Bracket
SKU # 4HL

  • Novel and patented unique DIY-friendly design allows any novice to create a beautiful hexagon shaped outdoor living space.
  • 2-way 60-degree heavy duty hexagon elbow bracket for 4×4 size lumber members.
  • Designed to create a strong 60-degree joint between two 4×4 lumber members and attach them to the end of a third 4×4 post.
  • Primarily to be used to create a hexagon shape or partial hexagon shape.
  • Highest quality materials and workmanship for high durability and long life.
    Smart DIY design allows easy, accurate, and safe assembly work.
  • Open U-channels allow easy and safe placement of header.
  • Decorative laser cut profiles provide refined aesthetics.
    Designed to create a permanent and strong 2-way 60-degree joints between two 6×6 members.
  • Can be use anywhere a strong 2-way joint is required.
    Can be positioned in any orientation.
  • 8-3/4” deep tube slides over any 4×4 post end.
    Allows bracket to be moved up or down at post ends for height adjustment, if necessary.
  • Heavy welded-on gussets under U-channel provides high load resistance and sway resistance. Eliminates the need for lumber gussets at corners.
    Predrilled 5/16” holes present, 2 holes in each vertical face of U-channels, for securing headers to the bracket using ¼”X 1-1/4” Lag Screws.
  • Four 5/16” holes present in two vertical tube walls to secure post to the bracket using ¼”X 1-1/4” Lag Screws.
  • 1/8” high strength steel, fully welded construction.
  • Black powder painted for corrosion resistance.

Specifications

Length =12-3/4″
Width = 12-3/4″
Height = 8-3/4″
Weight = 9.5 lbs.
Steel Thickness: 1/8″
Paint Type: Powder Paint
Paint Color: Black
