Double 2X Rafters to Single 2X Ridge Beam, 5-12 Pitch Rafter Tie Bracket – 9 Pack
Part Application Depiction
$490.50
SKU# D2X-RRT- 9 Pack
Title: Double 2X Rafters to Single 2X Ridge Beam, 5-12 Pitch Rafter Tie Bracket – 9 Pack
Out of stock
- This is a novel bracket designed to connect two Partial Hexagon Open End Rafters to the Ridge Beam.
- The Partial Hexagon Ridge Rafter Tie Bracket is designed to attach to the bottom and side surfaces of the main partial hexagon ridge beam and provide two rafter receiver U-channels at precise 23-degree angles.
- These brackets simplify addition of the ridge rafters at perfect angles to form strong support structure.
- The partial hexagon ridge rafter tie bracket attaches to the ridge beam’s bottom and side surfaces using six (6) 1/4″ x 1-1/4″ lag screws.
- The high strength design of this bracket holds the ridge rafters securely.
Facebook
Twitter
LinkedIn
Pinterest
James L.
Verified ownerMy project was not a normal one these were not stock rafter brackets. Raj did an excellent job of designing and making these brackets from a photo I e-mailed to him ,they were manufactured and shipped within a week and worked perfectly can't say enough good things about them , I would definitely order more if needed Thanks much for the excellent product and service ..
11 months ago
- This is a novel bracket designed to connect double 2X6, 2×8, or 2×10 Rafters to a single 2X Ridge Beam.
- This kit includes 9 brackets and all lag screws required to mount each bracket.
- This bracket is designed to attach to the bottom and side surfaces of the main ridge beam and provide two double rafters receiver U-channels at precise 23-degree angles.
- These brackets simplify addition of the ridge rafters at perfect angles to form a strong support structure.
- This bracket can also be fitted to existing raftered roof structures to provide additional strength.
- This bracket attaches to the ridge beam’s bottom and side surfaces using ten (10) 1/4″ x 1-1/2″ lag screws.
- The high strength design of this bracket holds the ridge rafters securely.
- This Bracket’s arms have upward facing open U-channels to easily receive 2×6 or 2×8 ridge rafters.
- Each pair of rafter is secured to the U-channel with eight (8) 1/4″ x 1-1/2″ lag screws.
- Included are forteen (26) 1/4″ x 1-1/2″ lag screws to complete the job.
- Don’t forget that you will have to drive 10D X 3″ nails at an angle to secure the top of the ridge rafters to the ridge beam. These 10D nails are not included.
- This bracket is constructed from 1/8″ thick high strength steel.
- This bracket is laser cut and formed and coated with durable black powder paint.
- This bracket may be spray painted over with any desired exterior-grade paint color.
SKU # D2X-RRT- 9 Pack Technical Specifications
| Weight | 60 lb |
|---|---|
| Dimensions | 24 × 24 × 14 in |
| Product Type | |
| Shape | Hexagon |
| Rafters Lumber Size | 2×6, 2×8 |
| Metal Thickness | 1/8" |
| Paint | Black Textured Powder Paint |
