Two Way 90-Degree Elbow Bracket
Two Way Elbow Bracket
SKU # 6C2L
- 2-way 90o heavy duty elbow bracket for 6×6 size lumber members.
- Designed to create a strong 3-way 90-degree joint between three 6×6 lumber members.
- Highest quality materials and workmanship for high durability and long life.
- Smart DIY design allows easy, accurate, and safe assembly work.
- Open U-channels allow easy and safe placement of header.
- Decorative laser cut profiles provide refined aesthetics.
- Designed to create a permanent and strong 3-way 90o joints between three 6×6 members.
- Can be use anywhere a strong 3-way joint is required.
- Can be positioned in any orientation.
- 11-1/4” deep tube slides over any 6×6 post end.
- Allows bracket to be moved up or down at post ends for height adjustment, if necessary.
- Heavy welded-on gussets under U-channel provides high load resistance and sway resistance. Eliminates the need for lumber gussets at corners.
- Four predrilled 7/16” holes present, 2 holes in each vertical face of U-channels, for securing headers to the bracket using 3/8”X 2” Lag Screws.
- Four 7/16” holes present in two vertical tube walls to secure post to the bracket using 3/8”X 2” Lag Screws.
- 1/8” high strength steel, fully welded construction.
- Black powder painted for corrosion resistance.
- Can be spray painted over, using any exterior grade paint
Specifications
Length =13-1/4″
Width = 13-1/4″
Height = 11-1/4″
Weight = 16.8 lbs.
Steel Thickness: 1/8″
Paint Type: Powder Paint
Paint Color: Black3/8
