5-12 Pitch Gable End Truss Rafter Bracket

Price range: $79.95 through $159.90

- +

5-12 Pitch Gable End Truss Rafter Bracket

Introducing our sturdy and reliable Universal Diy 5-12 Pitch Gable End Truss Rafter Bracket! This essential bracket is designed to provide added support and structural integrity to your roof’s gable end rafters. Made from high-quality materials, this bracket is built to last and ensure peace of mind for years to come.

Optimized for 2-pack low shipping price.

A purple 5-12 Pitch Gable End Truss Rafter Bracket with 14 black ½ x 1-1/4 lag screws arranged below it. Text labels specify the bracket SKU and screw quantity.
A 3D-rendered image shows two wooden beams joined at a right angle with a vertical post, secured by bright pink 5-12 Pitch Gable End Truss Rafter Brackets and black screws, against a wood-paneled background.
The 5-12 Pitch Gable End Truss Rafter Bracket is a black and gray metal corner bracket with screw holes, designed to join two beams at a right angle. It features three flat surfaces and is pictured against a white background.
The 5-12 Pitch Gable End Truss Rafter Bracket is a black, wall-mounted bracket with angled supporting arms and multiple screw holes, designed for secure attachment and a neat fit at the end of a gable roof truss.
The 5-12 Pitch Gable End Truss Rafter Bracket is a black metal connector with multiple screw holes, designed to join three beams at right angles; it features an upright slot for the central beam.
5-12 Pitch Gable End Truss Rafter Bracket made of black metal with a central hole, displayed on a beige surface. Twelve black screws are neatly arranged in three rows to the right of the bracket.
The 5-12 Pitch Gable End Truss Rafter Bracket, made of black metal with three T-shaped arms, is shown on a light wooden surface with a yellow measuring tape behind it to indicate its width.
3D diagram of a wooden pavilion frame showing labeled 5-12 Pitch Gable End Truss Rafter Brackets and connectors, with each bracket color-coded and marked by part code for use in 5-12 pitch roof assemblies.
A purple 5-12 Pitch Gable End Truss Rafter Bracket with 14 black ½ x 1-1/4 lag screws arranged below it. Text labels specify the bracket SKU and screw quantity.
A 3D-rendered image shows two wooden beams joined at a right angle with a vertical post, secured by bright pink 5-12 Pitch Gable End Truss Rafter Brackets and black screws, against a wood-paneled background.
The 5-12 Pitch Gable End Truss Rafter Bracket is a black and gray metal corner bracket with screw holes, designed to join two beams at a right angle. It features three flat surfaces and is pictured against a white background.
The 5-12 Pitch Gable End Truss Rafter Bracket is a black, wall-mounted bracket with angled supporting arms and multiple screw holes, designed for secure attachment and a neat fit at the end of a gable roof truss.
The 5-12 Pitch Gable End Truss Rafter Bracket is a black metal connector with multiple screw holes, designed to join three beams at right angles; it features an upright slot for the central beam.
5-12 Pitch Gable End Truss Rafter Bracket made of black metal with a central hole, displayed on a beige surface. Twelve black screws are neatly arranged in three rows to the right of the bracket.
The 5-12 Pitch Gable End Truss Rafter Bracket, made of black metal with three T-shaped arms, is shown on a light wooden surface with a yellow measuring tape behind it to indicate its width.
3D diagram of a wooden pavilion frame showing labeled 5-12 Pitch Gable End Truss Rafter Brackets and connectors, with each bracket color-coded and marked by part code for use in 5-12 pitch roof assemblies.
DOWNLOAD: PDF Installation Instructions
Explore Brackets & How-to-videos
Request Customized CutList and Instructions

5-12 Pitch Gable End Truss Rafter Bracket

Introducing our sturdy and reliable Universal Diy 5-12 Pitch Gable End Truss Rafter Bracket! This essential bracket is designed to provide added support and structural integrity to your roof’s gable end rafters. Made from high-quality materials, this bracket is built to last and ensure peace of mind for years to come. Whether you’re a DIY enthusiast or a professional contractor, our Gable End Rafter Bracket is the perfect solution for securing and reinforcing your roofing system. Upgrade your construction projects with this must-have accessory today!

Versatility

5-12 Pitch (23 degree) Gable end truss rafter bracket can be used for any building structure. This bracket can be employed for any project using 2×4, 2×6, or 2×8 rafters and ridge beam. Using this Gable End Truss Rafter Bracket, you can build a patio covering, garage roof, shed roof, greenhouse roof, and any rectangle gable roofed structure for any purpose. This bracket is commonly employed to build the gable end truss for 5-12 pitch Rectangle Pavilion roofs, Partial Hexagon Gazebo Roofs, and any 5-12 Pitch Gable Roofs.

Durability

Repair an old and weak gable end peak by adding this heavy duty bracket. Bring ultimate strength and new life to an old roof structure. Smart DIY design makes it so easy to create a strong truss for two ends of a gable roof.

Physical Properties

1/8″ thick steel, laser cut and welded, powder painted for rust proofing. Smart DIY design allows easy and accurate assembly work and allows easy creation of a super-strong truss structure for gable roof ends. (Qty 14) 1/4″ X 1-1/4″ Hex Hd Lag Screws included to secure two truss rafters and one ridge beam. This unique Gable End Truss Rafters Bracket is also listed at RioOutdoors.myShopify.com and at RioOutdoors.Etsy.com.

Technical Specifications

Weight 6 lb
Dimensions 16 × 8 × 6 in
Product Type

,

Shape

Hexagon
Rafters Lumber Size

2×6, 2×8
Metal Thickness

1/8"
Paint

Black Textured Powder Paint
Select A Multiple Pack

,

No additional boxes are available for this product.
